RF 2.4G Remote Control for 5-in-1 WiFi LED Controllers
Product Description
The RF 2.4G remote control is specially developed for operating 5-in-1 WiFi LED control systems and offers a fast, stable, and user-friendly way to control LED lighting. This remote control is suitable for DIM, CCT, RGB, RGBW, and RGBCW LED lighting, making it an ideal addition to WiFi-controlled installations.
Operation and functionality
The control interface consists of a color ring combined with 8 function buttons. This allows colors, brightness, white settings, and dynamic lighting effects to be adjusted easily and accurately. Thanks to RF 2.4 GHz wireless technology, the remote control operates without line-of-sight and offers a range of up to 30 meters, providing maximum flexibility.
5-in-1 compatibility
The remote control is a 5-in-1 model and can control multiple LED types, including single color (DIM), CCT (CW + WW), RGB, RGBW, and RGBCW. Two versions are available: RFBT02A for RGB, RGBW, and RGBCW applications, and RFBT02B for DIM and CCT applications. This makes the remote control suitable for both residential and professional installations.
Installation and ease of use
The remote control is supplied with a holder, ensuring it is always within easy reach. The holder can be mounted in two different ways, offering flexibility for wall or table mounting. The interface is clear and intuitive, allowing quick and hassle-free pairing and operation.
Technical characteristics
The remote control operates at a voltage of 3 volts using 2 AAA batteries. Wireless communication is via RF 2.4 GHz with a maximum range of up to 30 meters without directional limitations. Operation is via a color ring and 8 function buttons. The holder is included as standard and offers two mounting options.
Controller compatibility
This RF remote control is compatible with the following controllers: MINI001, D002, DLV003, DLV004, DLV005, D015, and D016.
Warranty
This remote control is supplied with a 3-year warranty. Damage caused by improper use, overloading, or external influences is excluded from the warranty conditions.
