CORE LINE – Compact LED Lighting for Spas, Hot Tubs and Swimming Pools
The XPRO POOL CORE LINE 3W LED pool light combines a compact design with energy-efficient LED technology and versatile installation options.
This LED light is specifically designed for spas, hot tubs, whirlpools, vinyl liner pools and compact swimming pools. Its small dimensions make it particularly suitable for installations where mounting space is limited.
With a power consumption of just 3 watts, the CORE LINE offers an energy-efficient solution for atmospheric underwater lighting.
The universal 1.5-inch threaded connection allows the light to be used in a wide range of new and existing installations.
The light is fully resin-filled and features an IP68 protection rating, making it suitable for permanent underwater installation when fitted according to the applicable installation requirements.
Choose Between Two Installation Options
To accommodate different installation requirements, the CORE LINE 3W LED light is available in two versions.
1. Without White Mounting Holder
This version includes only the CORE LINE 3W LED light with a 3-metre connection cable.
Ideal for replacing existing lighting where a compatible 1.5-inch threaded connection is already installed.
In many renovation projects, this allows the existing mounting arrangement to remain in place.
2. With White Mounting Holder
This version includes the CORE LINE 3W LED light and a matching white mounting holder.
The white mounting holder provides an installation option for locations where a suitable 1.5-inch connection is not already available, provided that the holder is compatible with the pool construction.
This combination is particularly useful for new spa, hot tub and swimming pool projects.
Important: The white mounting holder is included only when the With Mounting Holder option is selected during ordering.
Five Different Lighting Options
The CORE LINE 3W is available in five versions, allowing you to select the lighting that best suits your preferred atmosphere and existing electrical installation.
Cool White – Bright and Modern
The Cool White version produces crisp, bright white illumination.
This lighting option is suitable for swimming pools and spas where a modern appearance and clear lighting are desired.
Warm White – 3000K
Warm White creates a pleasant and relaxing atmosphere.
With a colour temperature of 3000K, this version is particularly suitable for hot tubs, spas and wellness environments.
The Warm White version delivers approximately 275 lumens.
Blue – Atmospheric Pool Lighting
The Blue version creates a distinctive blue lighting effect in swimming pools and hot tubs.
Ideal for decorative lighting in wellness areas and swimming pools where a calm, luxurious atmosphere is desired.
RGB+W – 2-Wire Connection
This version combines coloured LED lighting with a white light function and uses a 2-wire connection.
It is particularly suitable for renovation projects where the existing two-wire cabling needs to be retained.
The available colours, lighting programmes and control options depend on the compatible controller used.
RGB+W – 5-Wire Connection
The 5-wire RGB+W version features separate connections for the colour channels and the dedicated white light channel.
When combined with a suitable RGBW controller, different colours and lighting effects can be selected.
This version is designed for installations using a compatible 5-wire DC control system.
Please note: The 2-wire and 5-wire RGB+W versions use different electrical connections and control systems. Always check which version is compatible with your installation.
Universal 1.5-Inch Threaded Connection
The CORE LINE 3W features a 1.5-inch threaded connection, a commonly used connection size for compact underwater pool and spa lighting.
This makes the light suitable for various applications, including:
-
New spa and hot tub installations
-
Replacement of existing underwater lighting
-
Vinyl liner swimming pools
-
Compact private swimming pools
-
Wellness projects
-
Existing installations with a compatible 1.5-inch connection
Before ordering, always check the thread dimensions, available mounting space and electrical connection of the existing installation.
IP68 – Designed for Permanent Underwater Installation
The CORE LINE LED light is fully resin-filled.
This construction helps protect the internal LED components against moisture and water ingress.
The IP68 protection rating makes the light suitable for permanent underwater applications within the product's specified technical and installation conditions.
For reliable operation, it is essential that cable connections, wall penetrations and mounting components are correctly sealed and waterproofed.
Compact Dimensions and Wide Light Distribution
Measuring just 54 × 46 × 25 mm, the CORE LINE 3W is exceptionally compact.
The light features a 120° beam angle, distributing illumination across a relatively wide area.
Its low 3W power consumption makes it suitable for decorative and supplementary underwater lighting.
Key Features and Benefits
-
CORE LINE series: distinctive, compact LED swimming pool lighting.
-
3W LED power: energy-efficient operation.
-
1.5-inch threaded connection: suitable for a wide range of installations.
-
With or without white mounting holder: adaptable to new and existing installations.
-
Five lighting options: Cool White, Warm White, Blue and two RGB+W connection options.
-
IP68 protection rating: suitable for permanent underwater applications.
-
Fully resin-filled construction: protected LED components.
-
120° beam angle: wide light distribution.
-
3-metre connection cable: practical for installation and wiring.
-
Compact dimensions: ideal where mounting space is limited.
-
2-year warranty.
Technical Specifications
| Specification |
Details |
| Brand |
XPRO POOL |
| Product Series |
CORE LINE |
| Product Type |
LED Spa & Pool Light |
| Power |
3W |
| Light Dimensions |
54 × 46 × 25 mm |
| Threaded Connection |
1.5 inch |
| Operating Voltage |
12V AC/DC, depending on version |
| Protection Rating |
IP68 |
| Construction |
Fully resin-filled |
| LED Type |
Epistar 2835 |
| Number of LEDs |
34 |
| Beam Angle |
120° |
| Cable Length |
3 metres |
| Cool White |
Cool White |
| Warm White |
3000K |
| Blue |
Blue |
| RGB+W |
2-wire or 5-wire |
| Warm White Light Output |
Approx. 275 lumens |
| Lifespan |
Approx. 40,000 hours |
| Operating Temperature |
−25°C to +45°C |
| Mounting Holder |
Optional, white |
| Warranty |
2 years |
What's Included?
Version Without Mounting Holder
This version is suitable for installations with an existing, compatible mounting connection.
Version With White Mounting Holder
This version is intended for installations requiring the white mounting holder.
Not included with either version:
-
Transformer or power supply
-
Optional RGB+W controller
-
Additional installation accessories, unless explicitly stated
Important: Product photographs may show both the LED light and the optional white mounting holder. Only the components included in the selected product version will be supplied.
Important Installation Information
For safe and reliable operation, please observe the following guidelines:
-
Use only a suitable power supply that matches the selected light version.
-
Check that the existing cabling is compatible with the selected lighting option.
-
For RGB+W lighting, use a controller compatible with the relevant 2-wire or 5-wire system.
-
Check the available mounting space and 1.5-inch threaded connection before installation.
-
Ensure that cable connections and wall penetrations are correctly waterproofed.
-
Electrical connections must be installed in accordance with applicable safety regulations.
Important: Do not operate the light outside the water for longer than 30 seconds.
XPRO POOL CORE LINE – The Right Lighting for Every Spa and Hot Tub
With the XPRO POOL CORE LINE 3W, you choose a compact, versatile and energy-efficient LED solution for underwater lighting.
Whether you are replacing an existing light or installing lighting in a new project, the five available lighting options and the choice between versions with or without a mounting holder allow you to select the right combination for your installation.
XPRO POOL – Pool & Spa lighting solutions.
