PRO LINE Underwater Spotlight Stainless Steel 316L Ø180 mm
12W – 18W – 25W | IP68 | 12V AC/DC | Warm White or RGB

---

The PRO LINE Ø180 mm Underwater Spotlight is a powerful and professional LED lighting solution, designed for illuminating ponds, swimming pools, fountains, and architectural water projects. With its wide diameter of Ø180 mm, slim height of only 47 mm, 9 Epistar LED chips, and a robust 316L stainless steel housing fully resin-filled, this spotlight delivers maximum light output with minimal installation depth.

Available in 12W, 18W, and 25W, it ensures the right lighting level for every project.

---

Light Output per Version

Choose the power level that suits your application:

12W warm white – 1,008 lumens
18W warm white – 1,458 lumens
25W warm white – 1,876 lumens

12W RGB – 540 lumens
18W RGB – 846 lumens
25W RGB – 1,075 lumens

The spotlight is equipped with 9 Epistar LED chips, known for reliability and energy efficiency. The 60° beam angle ensures wide and even light distribution.

---

Available in Warm White or RGB

The PRO LINE Ø180 mm is available in two lighting options:

• Warm white — for natural and atmospheric lighting
• RGB — for dynamic color effects, optionally controllable via WiFi or smart control systems (4-wire connection)

---

Maximum Waterproofing – IP68

The internal structure is fully resin-filled, making the spotlight 100% waterproof and suitable for permanent underwater installation. The IP68 rating protects against:

• Water pressure
• Dirt and moisture
• Temperature fluctuations
• Mechanical stress

---

Durable Materials for Intensive Use

The PRO LINE underwater spotlight is built for demanding environments:

• Housing: 316L stainless steel — excellent corrosion resistance, even in salt and chlorinated water
• Front and body: Anti-UV PC — resistant to UV and discoloration
• Internal structure: fully resin-filled — optimal protection and heat dissipation

---

Flexible Installation and Smart Control

The spotlight supports two connection options:

• 2-wire — standard connection for warm white
• 4-wire — for RGB smart control via WiFi or remote control

The included 2-meter cable ensures easy and flexible installation, even in hard-to-reach locations.

---

Suitable for

This powerful spotlight is ideal for:

• Pond lighting
• Swimming pool lighting
• Fountain and waterfall lighting
• Decorative water features
• Architectural water installations
• Professional landscaping projects

---

Key Features

✔ Powerful underwater spotlight — Ø180 × 47 mm (wide, flat design)
✔ Power options: 12W / 18W / 25W
✔ Light output up to 1,876 lumens
✔ Available in warm white or RGB
✔ IP68 — fully waterproof
✔ 9 × Epistar LED chips
✔ 60° beam angle for wide light distribution
✔ Safe 12V AC/DC operation
✔ 2-wire or 4-wire connection
✔ Energy class A+
✔ Lifespan up to ±50,000 hours
✔ 2-meter cable included
✔ 2-year warranty

---

Technical Specifications

Model: PRO LINE HJ-SL180
Dimensions: Ø180 × 47 mm
Power: 12W / 18W / 25W
Voltage: AC 12V / DC 12V
Light output warm white: 1,008 / 1,458 / 1,876 lm
Light output RGB: 540 / 846 / 1,075 lm
Beam angle: 60°
LED chips: 9 × Epistar
Connection: 2-wire / 4-wire
Cable length: 2 meters
IP rating: IP68 — fully waterproof
Housing material: 316L stainless steel
Front/body material: Anti-UV PC
Internal structure: fully resin-filled
Operating temperature: -20°C to +35°C
Energy class: A+
Lifespan: up to ±50,000 hours
Warranty: 2 years

PRO LINE Underwater Spotlight Stainless Steel 316L Ø146 mm
9W – 18W – 25W | IP68 | 12V AC/DC | Warm White or RGB

---

The PRO LINE Ø146 mm Underwater Spotlight is a powerful and professional LED lighting solution, designed for illuminating ponds, swimming pools, fountains, and architectural water projects. Featuring 9 Epistar LED chips, a robust 316L stainless steel housing, and a fully resin-filled interior, this spotlight ensures maximum waterproofing, corrosion resistance, and long lifespan.

Available in 9W, 18W, and 25W, it offers the right light output for every application.

---

Light Output per Version

Choose the power level that suits your project:

9W warm white – 756 lumens
18W warm white – 1,314 lumens
25W warm white – 1,725 lumens

9W RGB – 404 lumens
18W RGB – 702 lumens
25W RGB – 875 lumens

The spotlight is equipped with 9 Epistar LED chips, a reliable A-brand known for energy efficiency and stable performance. The 60° beam angle ensures wide and even light distribution.

---

Available in Warm White or RGB

The PRO LINE Ø146 mm is available in two lighting options:

• Warm white — for natural and atmospheric illumination
• RGB — for dynamic color effects, optionally controllable via WiFi or smart control systems (4-wire connection)

---

Maximum Waterproofing – IP68

The internal structure is fully resin-filled, making the spotlight 100% waterproof and suitable for permanent underwater installation. The IP68 rating guarantees protection against:

• Water pressure
• Dirt and moisture
• Temperature fluctuations
• Mechanical stress

---

Durable Materials for Intensive Use

The PRO LINE underwater spotlight is built for demanding environments:

• Housing: 316L stainless steel — excellent corrosion resistance, even in salt and chlorinated water
• Front and body: Anti-UV PC — resistant to UV and discoloration
• Internal structure: fully resin-filled — optimal protection and heat dissipation

---

Flexible Installation and Smart Control

The spotlight supports two connection options:

• 2-wire — standard connection for warm white
• 4-wire — for RGB smart control via WiFi or remote control

The included 2-meter cable allows for easy and flexible installation, even in hard-to-reach areas.

---

Suitable for

This powerful spotlight is ideal for:

• Pond lighting
• Swimming pool lighting
• Fountain and waterfall lighting
• Decorative water features
• Architectural water installations
• Professional landscaping projects

---

Key Features

✔ Powerful underwater spotlight — Ø146 × 126 × 180 mm
✔ Power options: 9W / 18W / 25W
✔ Light output up to 1,725 lumens
✔ Available in warm white or RGB
✔ IP68 — fully waterproof
✔ 9 × Epistar LED chips
✔ 60° beam angle for wide light distribution
✔ Safe 12V AC/DC operation
✔ 2-wire or 4-wire connection
✔ Energy class A+
✔ Lifespan up to ±50,000 hours
✔ 2-meter cable included
✔ 2-year warranty

---

Technical Specifications

Model: PRO LINE HJ-SL146
Dimensions: Ø146 × 126 × 180 mm
Power: 9W / 18W / 25W
Voltage: AC 12V / DC 12V
Light output warm white: 756 / 1,314 / 1,725 lm
Light output RGB: 404 / 702 / 875 lm
Beam angle: 60°
LED chips: 9 × Epistar
Connection: 2-wire / 4-wire
Cable length: 2 meters
IP rating: IP68 — fully waterproof
Housing material: 316L stainless steel
Front/body material: Anti-UV PC
Internal structure: fully resin-filled
Operating temperature: -20°C to +35°C
Energy class: A+
Lifespan: up to ±50,000 hours
Warranty: 2 years

PRO LINE Fountain Light Stainless Steel 316L Ø158 mm

12W – 18W | IP68 | 12V / 24V AC/DC | Warm White, RGB or RGBW

The PRO LINE Ø158 mm fountain light is a compact and powerful professional LED spotlight, designed for illuminating fountains, ponds, water features, and architectural water installations. Thanks to its robust stainless steel 316L housing and low-profile design, this fixture is ideal for recessed installations.

The light is equipped with 6 high-power LEDs, providing strong and uniform light distribution.

---

Light Output per Version

12W:

• 3000K – 900 lumens
• 4500K – 984 lumens
• 6000K – 1056 lumens
• RGB – 552 lumens
• RGBW – 672 lumens

18W:

• 3000K – 1332 lumens
• 4500K – 1458 lumens
• 6000K – 1548 lumens
• RGB – 774 lumens
• RGBW – not available

---

Beam Angle Options

• 15° — narrow beam for accents and water jets
• 30° — focused lighting
• 45° — balanced spread
• 60° — wide illumination

---

Warm White, RGB or RGBW

• Warm White (3000K) — warm and atmospheric lighting
• RGB — dynamic color-changing effects
• RGBW — enhanced colors with white light support (12W only)

---

Compact and Low-Profile Design

The fixture has a very slim profile:

• Ø158 mm × height 40 mm

Ideal for flush mounting in fountain basins and water structures without protruding parts.

---

Fully Waterproof – IP68

Suitable for permanent underwater installation and resistant to:

• Continuous submersion
• Chlorine and salt water
• Temperature fluctuations
• Dirt and deposits

---

Materials

• Housing: Stainless Steel 316L
• Lens: tempered glass
• LEDs: 6 high-power LEDs

---

Cable & Connection

• Cable: 3 × 1.0 mm²
• Length: 2.5 meters
• Protection: built-in overheating protection

---

Power Supply

• 12V / 24V AC/DC
• Safe and suitable for professional installations

---

Applications

Suitable for:

• Fountains
• Ponds
• Water features
• Waterfalls
• Public projects
• Hotels & wellness environments

---

Key Features

✔ Diameter: Ø158 mm
✔ Height: 40 mm
✔ Power: 12W / 18W
✔ 6 high-power LEDs
✔ Light output up to 1548 lumens
✔ RGB & RGBW (RGBW only for 12W)
✔ 4 beam angles
✔ IP68 waterproof
✔ 12V / 24V AC/DC
✔ Stainless Steel 316L housing
✔ Tempered glass lens
✔ 2.5 meter cable
✔ 2-year warranty

---

Technical Specifications

• Application: fountain lighting
• Dimensions: Ø158 × H40 mm
• Material: Stainless Steel 316L
• Lens: tempered glass
• LED quantity: 6
• Power: 12W / 18W
• Voltage: 12V / 24V AC/DC
• Light output:
  • 12W: 900 / 984 / 1056 lm (3000K / 4500K / 6000K)
  • 18W: 1332 / 1458 / 1548 lm
  • RGB: 552 / 774 lm
  • RGBW: 672 lm (12W only)
• Beam angle: 15° / 30° / 45° / 60°
• Cable: 3×1.0 mm² – 2.5 m
• IP rating: IP68
• Warranty: 2 years
